The Semiprobe PS4L Probe Station is a manual prober used for electrical characterization of wafer-level or chip-level devices. A Keithley 4200A SCS Parameter Analyzer is integrated with this probe station. This analyzer is highly accurate and versatile as it comes equipped with a Source Measure Unit (SMU), an ultrafast Pulse Measure Unit (PMU), and a Remote Preamplifier/Switch Module (RPM).
Probe Station Features:
Wafer Sizes: Up to 8″
Heating and Cooling: -60°C to 300°C
Isolation: Dark Box and Vibration Isolation Table
Parameter Analyzer Features:
OS: Windows 10
4211-SMU:
– High power: Up to 21W, 1A range, and ±210V
– High low current stability
– Resolution down to 10aA w/ RPM
4225-PMU:
– Measure range: ±40V and ±800mA
– Minimum Pulse Width: 20ns
– Simultaneous I & V Measurements
4225-RPM:
– Enhanced resolution for PMU and SMU
– Allows automatic switching between PMU and SMU
Coming Soon: Probe Station SOP
Coming Soon: Keithley Parameter Analyzer SOP
See Current Trainer List for trainer to contact.
